产品简介:
选配表
|
底座型号\阀型号 |
4V100 |
4V200 |
4V300 |
4V400 |
|
100M |
● |
|
|
|
|
200M |
|
● |
|
|
|
300M |
|
|
● |
|
|
400M |
|
|
|
● |
|
型号\符号 |
A |
B |
C |
E |
F |
G |
H |
I |
J |
K |
L | ||||||
|
1F |
2F |
3F |
4F |
5F |
6F |
7F | |||||||||||
|
100M□F |
58 |
43.2 |
20 |
4.5 |
18.3 |
19 |
5 |
10 |
28.2 |
139.4 |
38 |
57 |
76 |
95 |
114 |
133 |
152 |
|
200M□F |
61 |
50.7 |
21 |
4.5 |
22.4 |
23 |
6 |
12 |
31.7 |
170 |
46 |
69 |
92 |
115 |
138 |
161 |
184 |
|
300M□F |
75 |
64.8 |
26 |
4.5 |
27.3 |
27 |
6 |
13.5 |
40 |
188.8 |
54 |
82 |
110 |
138 |
166 |
194 |
222 |
|
400M□F |
104 |
94.5 |
32 |
5.5 |
34.3 |
31.5 |
7 |
14.5 |
57 |
221.8 |
63 |
98 |
133 |
168 |
203 |
238 |
273 |
|
型号\符号 |
L |
M |
P | |||||||||||||
|
8F |
9F |
10F |
11F |
12F |
13F |
14F |
15F |
16F |
1F |
2F |
3F |
4F |
5F |
6F | ||
|
100M□F |
171 |
190 |
209 |
228 |
247 |
266 |
285 |
304 |
323 |
154.5 |
28 |
47 |
66 |
85 |
104 |
123 |
|
200M□F |
207 |
230 |
253 |
276 |
299 |
322 |
345 |
368 |
391 |
189 |
34 |
57 |
80 |
103 |
126 |
149 |
|
300M□F |
250 |
278 |
306
| |||||||||||||
